| Stock Box (standard) |
1139x1900x1250 with flared top |
| Cutting Rotor |
1173x550mm |
| Cutting Tools |
96x40mm square (4 sided and turnable) |
| Rotor Speed |
50-100rpm |
| Particle Size |
5-50mm depending on screen perforation |
| Screen Size - specified |
40mm diameter perforation |
| Power - Main Motor |
55kw |
| Power - Hydraulic Pack |
7.5kw with fast approach/reverse |
| Capacity (estimated) |
2-8 box loads per hour |
| Waste Outlet |
Gravity discharge below screen or air extraction |
| Supply - Mains |
380-415/3/50 + neutral |
| Supply - Control |
24v ac |
| Control Panel |
Wall mounted pre-wired cable to sredder |
| Control PC |
Mitsubishi FXO plc |
| Weight |
6550kg |
| Overall Dimensions |
4096x2315x2855mm |
| Noise |
Up to 85 db(A) in operation at 1 metre from machin |
