| Stock Box |
857mm x 1478mm x 1020mm with flared top |
| Cutting Rotor |
887mm x 270mm |
| Cutting Tools |
33 x 30mm square (4 sided and turnable) |
| Rotor Speed |
50-100rpm |
| Particle Size |
5-50mm depending on screen perforation |
| Screen size - specified |
As required |
| Power - Main Motor |
18.5kw |
| Hydraulic Pack |
4.0kw with fast approach/reverse |
| Capacity |
1-5 box loads per hour |
| Waste Outlet |
Gravity discharge below screen or air extraction |
| Supply - Mains |
380-415/3/50 + Neutral |
| Control |
24v a.c. |
| Control Panel |
Wall mounted pre-wired cable to shredder |
| Control PC |
Mitsubishi FXO plc |
| Weight |
2850kg |
| Overall Dimensions |
3141mm x 1827mm x 2130mm |
| Noise |
Up to 85dB(A) in operation at 1 metre from machine |
