Blue Diamond Shavings Machines for Sale

What are Blue Diamond Wood Shaving Machines?

Blue Diamond Wood Shaving Machine are a range of professional shaving machines capable of sustained production of up to 6 tonne of high quality shavings per hour

How a Blue Diamond Wood Shaver works

The BLUE DIAMOND Shavings Machine comprises one or two log holding boxes, which travel back and forth over the top of the cutter heads, two under each box.

Shaving Process

Shavings are produced by the "planing" of the logs, the quality and specification of the shavings being influenced by the speed of the log box and the setting of the knives in the cutterheads as well as by the species and condition of the logs.

Shavings Collection

The shavings are discharged below the cutterheads, where they can be collected and removed by optional conveyors.

Log Feeding

The log holding boxes are driven through a differential gearbox linked to heavy roller chains attached with shock absorbing cushion hitches to ensure a smooth travel. The log holding boxes are most commonly loaded from a central position with an operator pushing or rolling the logs from a log haul chain or from a central log deck. Optional automatic log loading arrangements are also available.

The Blue Diamond Wood Shaving Machine in action

View our video to see Blue Diamond Wood Shaving Machine in action

Why we chose to become the UK Agent for Blue Diamond Wood Shaving Machinery

Requirement

TCR were approached by various specialist suppliers of shavings to source a shavings machine for the production of consistently high quality wood shavings from round logs suitable for animal bedding and poultry bedding.

Solution

TCR are pleased to have located the Blue Diamond, which we have now supplied to several UK companies who specialise in the supply of high quality shavings into the poultry bedding and equestrian bedding markets.

Experience

Due to the success of our Blue Diamond installations in the UK, TCR have now agreed with the original manufacturers of the BLUE DIAMOND that all machines sold into Europe can now be manufactured here in the UK. TCR have recently supplied our first UK built machine complete with electrical panel and motors into Ireland.

Without reservation they are very satisfied with the quality of the woodshavings produced by the BLUE DIAMOND shaving machines. Several of our customers have already taken delivery of their second twin box machine and have already have ordered the installation of further machines.

sawmill machinery

What is the Technical Specification of the Blue Diamond Wood Shaving Machine

Technical Specification of the Blue Diamond Wood Shaving Machine

  • Log Holding Boxes
  • Log Box Drive
  • Log Box Chain
  • Cutterheads 10" diameter cutterhead knives
  • 12 per head x 40" wide with quick setting system
  • Cutterhead drive unit - 4 x 37.5kW motors
  • Noise levels in excess of 100dba requires sound-proofing

How do I purchase a Blue Diamond Shavings Machine in the UK and Europe?

TCR are the UK/Europe Agent for Blue Diamond Shavings Machine

For more information and to discuss your requirements please contact us on 0151 549 2570
Clickl here to view our contact details
