| Stock Box (standard) |
571x1154x850mm with flared top |
| Cutting Rotor |
601x270mm |
| Cutting Tools |
22x30mm square (4 sided and turnable) |
| Rotor Speed |
70-140rpm |
| Particle Size |
5-50mm depending on screen perforation |
| Screen Size - specified |
40mm diameter perforation |
| Power - Main Motor |
15kw |
| Power - Hydraulic Pack |
0.75kw with fast approach/reverse |
| Capacity (estimated) |
2-4 box loads per hour |
| Waste Outlet |
gravity discharge below screen or air extraction |
| Supply - Mains |
380-415/3/50 + neutral |
| Supply - Control |
24v ac |
| Control Panel |
Wall mounted pre-wired cable to sredder |
| Control PC |
Mitsubishi FXO plc |
| Weight |
1850kg |
| Overall Dimensions |
2062mmx1320x1870mm |
| Noise |
Up to 85 db(A) in operation at 1 metre from machin |
