| - Feed Motor |
7.5kw |
| Cutting Rotor (1) |
265mm diameter x 686mm long |
| Control Panel |
Floor Standing panel pre-wired to machine |
| Log Box (standard) |
1300mm long x 645mm wide x 1200mm high |
| Mark 2 Cutting Rotor (1) |
265mm diameter x 686mm long |
| Cutting Tools |
12 X Knives |
| Rotor Speed |
2750 - 3000 rpm |
| Shaving Size |
Adjustable to suit customer requirements |
| Power - Rotor Motor |
1 x 30kw |
| Motor for Hydaulic Feed |
7.5kw |
| Capacity (estimated) |
Up to 2 tonne (wet) per hour |
| Shavings Outlet |
Gravity Discharge below rotor |
| |
onto short belt conveyor |
| Supply - Mains |
380-415/3/50 + Neutral |
| - Control |
24v a.c. |
| Floor Standing Control Panel |
Push Button Panel pre-wired to machine |
| Optional (at extra cost) |
PLC Panel with Remote Control |
| Weight |
3300kgs |
| Overall Dimensions |
5394mm (L) x 2180mm (W) x 3200mm (H) |
| Sound Installation |
At extra cost subject to site survey |
| Delivery |
10 - 12 weeks |
